모듈 Module

NE1800-017

Specifications

This specification defines the characteristics of a rechargeable lithium ion battery manufactured by ENERTECH INTERNATIONAL INC.
enertech

SPECIFICATION

No Item Need to change of specification
1 Nominal Capacity(KWh) 180Ah(2.66kWh)
2 Nominal Voltage(Operating Voltage) 14.8V(10.8~16.8V)
3 Charging Current Standard 54A
Maximum 180A
4 Discharging Current Standard 54A
Maximum 360A
5 Operating Temperature Charge 0 ~ 55℃
Discharge -20 ~ 55℃
6 Dimension Height(Z) 109.5mm
Width(Y) 165mm
Length(X) 360mm
7 Weight < 12.2Kg
